Description

HDMI 2.1 Detachable HDMI AOC-8K@60Hz

The Link Aura LA-AOC-8KHD2A Series Armored HDMI Active Fiber Optic UHD Pluggable HDMI Cable is perfect for
demanding and adaptable installations. This cable supports HDMI data rates up to 12Gbps per channel, with a
total bandwidth of 48Gbps. It features a lightweight and flexible design with an ultra-small bending radius of 45mm,
ideal for long-term use. Equipped with advanced optical technology, the cable ensures complete HDMI signal
integrity over distances of up to 100 meters. It offers a hassle-free, plug-and-play experience without the need
for external power.

Features

• Compatible with HDMI 2.1 standard: EDID, CEC, HDCP2.3, Dynamic HDR, HEC, eARC etc.
• Supports resolutions up to 7680 x 4320 (8K)@60Hz 4:4:4
• Data transfer rates up to 48Gbps
• Supports DSC, VRR, QMS, QFT, ALLM
• No signal loss – delivering crystal clear digital images instantly
• Cable OD: 5.8mm, 4 fiber + 7 copper wire
• Up to 100m Maximum Length (custom lengths available, recommended ≤30m for eARC)
• OM3 fiber technology reduces EMI/RFI emissions
• Triple-shielding for optimal signal quality
• Extended temperature range: -40°C to 70°C
• Available in PVC, CL2, CL3, CMP, and LSZH jackets (fire-safe)
• Source & Display clearly printed on connector for easy identification
• High pulling strength and compression load
• Plug-and-play, no external power required
• 200CU stainless steel construction

Applications

• Digital Signage & LED signboards (streets, stadiums)
• Medical Imaging Equipment
• Airplane On-board Video Systems
• Home Theater, Blu-ray, 3D videos, Projectors, Set-top boxes, DVRs, Game Consoles, Computers
• TV Broadcast Stations
• Conference Room Video Equipment
• Security Systems

Ordering Information
